Bando 100-S5M-520 HP -STS S5M-520 TB – One-stop shop for professional tools and equipment.

Description

Product Description

Bando – 100-S5M-520 HP Anticipating the demand for energy savings and higher horsepower transmission, Bando developed our High Performance STS (HPSTS) belt, utilizing our time-proven technology and experience.

• High durometer oil and heat resistant, static conductive synthetic rubber protect against tooth deformation, minimizing fatigue.
• Tooth canvas provides a low coefficient of friction, lowering noise levels.
• This HPSTS belt achieves exceptionally higher power transmission – up to 2 times as high as conventional STS belts.
• Higher HP transmission minimizes the width of the belt, making system design as compact as possible.
• The narrower width of the belt and pulleys results in a quieter running drive.
• Runs in standard stock STS pulleys.
• HPS 5M is only available in clean specification, minimizing rubber dust.

Additional Information

Price Class530

Weight (lbs)0.04

Number of Teeth104

Tooth Pitch (In)0.1969

Tooth Pitch (mm)5

Tooth ProfileS5M

Multiplier0.3392

Belt Width (In)0.394

Belt Width (mm)10

ColorBlack

Ribs/Teeth/Angle104

CordFiberglass

Height (In)0.1421

Height (mm)3.61

MaterialSynthetic Rubber

Nominal Outside Length (In)20.4724

Nominal Outside Length (mm)520
