Description

Product Description

Delta Breez – SIG80-110 Delta Breez SIG80-110 – Innovative brushless DC motor design for long life, low noise, and low power consumption

Delta Breez model SIG80-110 has been awarded ENERGY STAR® qualified with brushless DC motor engineered to run continuously for a minimum 70,000 hours; airflow rating of 110 CFM and loudness rating of less than 0.3 Sones at 0.1” static pressure as certified by the Home Ventilating Institute (HVI); power consumption of 8.2 Watts with efficiency rating of 15.3 CFM/Watt at 0.1” static pressure; fan will feature motor lock protection and self-compensating motor speed for intended airflow when static pressure is encountered. UL and cUL listed for tub/shower enclosure when used with GFCI-protected branch circuit wiring.

Features

• ENERGY STAR^® qualified with innovative brushless DC motor technology
• Perfectly quiet operation at less than 0.3 sones
• Full speed adjustable, 80 CFM or 110 CFM
• Includes 6″ to 4″ duct reducer
• Energy efficiency at 15.4 CFM/Watt
• White Grille
• LED indicator light will be green when power is on

SIG80-110 – 80/110 CFM Exhaust Fan (6″ Duct Standard)

Additional Information

Static Pressure (inches w.g.)0.1

Air Flow (CFM)80, 110

Sones0.3

Power Consumption (Watts)6.2, 8.2

Energy Efficiency (CFM/Watts)15.4, 15.3

Current (Amps)0.38 Max

Power Rating (V/Hz)120/60

SIG80-110 – 80/110 CFM Exhaust Fan (4″ Duct Standard)

Additional Information

Static Pressure (inches w.g.)0.1

Air Flow (CFM)80, 110

Sones0.3, 1

Power Consumption (Watts)7.4, 12

Energy Efficiency (CFM/Watts)12.5, 10.5

Current (Amps)0.38 Max

Power Rating (V/Hz)120/60
