Siemens 536-768 OUTSIDE AIR TEMPERATURE SENSOR, THROUGH-THE-WALL, 4 TO 20 MA – One-stop shop for professional tools and equipment.

Description

Product Description

Siemens – 536-768 Outside Air Temperature Sensor, Through-the-wall, 4 to 20 mA

This outdoor air sensor provides input for accurate loop-powered temperature sensing for controllers. It has a temperature range of -58 to 122 degrees Fahrenheit and a mid-range accuracy of +/- 0.6 degrees Fahrenheit. This sensor allows through-the-wall mounting for outside air temperature measurements and provides a 4 to 20 mA control signal; uses metal housing.

Additional Information

Measuring range, temperature-50…50 °C

Sensing element100 ohm Platinum RTD

Operating voltage18 to 36Vdc or 24Vac ± 20 %

Analog outputs4 to 20 mA

Measuring range-58 to 122 °F

Measurement accuracy+/-0.54°F @ 32 °F

Material, housingMetal

Sensing elementPt100
