Winters Instruments PCT333 Pct Contractor Pressure Gauge/ Pct-Lf Lead Free Contractor Gauge – One-stop shop for professional tools and equipment.

Description

Product Description

Winters Instruments – PCT333

Features

• Economical 4.5” (115mm) stainless steel case gauge
• Brass or lead free brass wetted parts
• ±1% accuracy
• Zero adjustment screw
• 1/4” NPT
• Restricted orifice
• ASME B40.100 compliant
• CRN registered
• Lead free version NSF-61-372 certified
• 5 year warranty

Applications

• Most commercial air, water and steam services (with syphon)
• Lead free version for potable water systems

Additional Information

Dial4.5” (115mm) white aluminum dial with black and red markings

Case304 SS

LensAcrylic

Ring304 SS

SocketPCT: Brass, PCT-LF: Lead free brass, NSF-61-372 certified

Connection1/4” NPT standard

Bourdon TubePhosphor bronze

MovementPCT: Brass, PCT-LF: Lead free brass, NSF-61-372 certified

PointerAluminum, anodized black, recalibrator screw

WeldingSilver solder

Over-Pressure Limit25% for pressures up to 1,450 psi (9,998 kPa), 15% for pressures over 1,500 psi (10,342 kPa)

Working PressureMaximum 75% of full scale value

Ambient/Process Temperature-40°F to 200°F (-40°C to 93°C)

Accuracy±1% ANSI/ASME Grade 1A

Enclosure RatingIP52
